Inorganic liquid compounds with high temperature resistance in order to stick ceramic fiber products to furnace walls and roof. Thermal coating is used to cover the surface of insulations to increase resistance to cracking and spalling.
Technical Information for Thermal Paste, Mastic & Coating
Grade |
1000 |
1600 |
|
Classification Temp. (ºc) |
1000 |
1400 |
1600 |
Color |
Gray |
Gray |
Gray |
Ignition Limit (ºc) |
³1600 |
³1700 |
³1700 |
Safe-working Temp. (ºc) |
£1000 |
£1400 |
£1500 |
Density (kg/m³) , ASTM C167 |
1500 |
1500 |
1500 |
Thermal Conductivity (at 1000C°) (W/m.K) ,ASTMC201 |
0.2-0.3 |
0.2-0.3 |
0.2-0.3 |
Chemical Analysis (%) |
|||
Al2O3 |
19 |
62 |
70 |
SiO2 |
65 |
28 |
18 |
Fe2O3 |
2 |
2 |
1.5 |
K2O + Na2O |
7 |
- |
- |
Other |
7 |
8 |
10.5 |
Packing |
30 KG Pail |
